Mechanical Lab

Overview Equipments Testing Charges Staff Training Gallery

Overview

Overview text will come herere

Equipments

Sr. No. Equipment / Tool Company Make Usage
1. Dry & Wet Thermometer( -15 TO 50°C) ZEAL For Temperature Check
2. Whirling Hygrometer( -5 TO 50°C) ZEAL For Temperature Check
3. Filament Tester ZWEIGLE For Filament check
4. Load Cell- 5KN LLOYD For Yarn & Fabric Strength
5. Load Cell- 50N LLOYD For Yarn & Fabric Strength
6. Auto Wrap MAG For Denier Check
7. Electronic Balance ( Max.120g) SHIMADZU For Weight Check
8. Electronic Balance ( Max. 22g) AND For Weight Check
9. Measuring Scale - 0 to 450 mm AJANTA For Length Measurement
10. Measuring Scale - 0 to 610 mm SHARP For Length Measurement
11. Measuring Scale - 0 to 1000 mm AJANTA For Length Measurement
12. Measuring Scale - 0 to 1000 mm AJANTA For Length Measurement
13. Measuring Scale - 0 to 300 mm AJANTA For Length Measurement
14. Measuring Tape - 0 to 3000 mm FREEDOM For Length Measurement
15. Twist Tester(0 to 3000 TPM) Digital Tachometer MAG For Twist Measurement
16. G.S.M. Template(10 X 10 cm) J J SONS For G.S.M. Check
17. G.S.M. Template(25 X 25 cm) J J SONS For G.S.M. Check
18. Pick Glass(1 inch) A-ONE For Threads per inch Measurement
19. Abrasion Tester ( 0 to 50 RPM) MAG For Pilling Test

Testing Price List

Parameters Testing standards Testing charges ₹ (With G.S.T.)
Standard test method for Linear Density of Yarn (Yarn Number) by the Skein Method ASTM
D 1907/D1907M-12 (2018)		 177
Standard test method for Twist in Yarn by Direct Counting ASTM D1423 / D1423M - 16 (2022) 295
Standard test method for Tensile Properties of Yarn by the Single-Strand Method ASTM D2256 / D2256M(2021) 413
Standard test method for Warp End Count and Filling Pick Count of Woven Fabric. ASTM D3775 - 17e1(2018) 236
Standard test method for Yarn Number Based on Short-Length Specimens MANTRA/M
/LAB TM-02(2012)
(In-House Test Method)		 177
Standard test method for Number of Filaments in Yarn MANTRA/M/LAB TM-01(2009)
(In-House Test Method)		 295
Standard test method for Length of Woven Fabric.(Option A-Hand, Option D-Folding) ASTM D3773 / D3773M - 10(2019) 177
Standard test method for Width of Woven Fabric. ASTM D3774 - 18 177
Standard test method for Mass Per Unit Area (Weight) of Fabric(Option C) ASTM D 3776 / D3776M (2020) 236
Standard test method for Mass Per Unit Area (Weight) of Fabric(Method 5) ISO 3801:1977 (E) 236
Standard test method for Mass Per Unit Area (Weight) of Fabric (Method A) IS 1964:2001 (2017) 236
Tearing strength of fabrics by falling pendulum (Elmendorf-type) apparatus ASTM D 1424-21(2021) 708
Tearing strength of fabrics by falling pendulum (Elmendorf-type) apparatus ISO 13937-1(2000) (E) 708
Standard test method for Breaking Force and Elongation of Textile Fabrics
(Strip Method)		 ASTM D5035 - 11(2019) 826
Standard test method for Breaking Force and Elongation of Textile Fabrics
(Strip Method)(Part-1)		 IS 1969-1 (2018) 826
Standard test method for Breaking Force and Elongation of Textile Fabrics
(Strip Method)		 ISO 13934-1(2018) 826
Fabric propensity to surface fuzzing and to pilling Part 2: Modified Martindale method ISO 12945-2:2020 590
Fabric propensity to surface fuzzing and to pilling Part 2: Modified Martindale method ASTM D 4970/D 4970M-16e3(2018) 590
Boiling Water Shrinkage of Yarn - 354
Crease Recovery - 260
Nips Per Meter - 236
Count Strength Product - 649
Count - 177
Weight Per Linear Meter - 177
Type of Process of Yarn - 201
Yarn Cross Section - 472
Hot/Cold Water Fabric Shrinkage - 354
Total No. of Ends - 944
Thickness of Material - 177
Width of Jari Material - 177
Hot Crimp Contraction - 354
Crimp Regidity - 354
Yarn Unevenness (Staple/Filament) - 708
Calculated Length of Embroidery Yarn - 472

Staff

Sr. No. Name Designation Date of Joining Expertise
1. Dinesh M. Prajapati Technical Officer 18/10/2023 Testing
2. Jayantibhai K. Patel Senior Scientific Assistant 15/06/2016 Testing & Technical work
3. Kirit N. Vyas Technical Officer 09/01/2023 Testing
4. Sandip M. Pathak Technical Lab Assistant 11/11/2002 Testing
5. Dharmesh D. Rana Junior Scientific Officer 06/04/2023 Testing & R&D work
6. Jagdish M. Trivedi Peon 10/12/1997 Helper

Training

Sr. No. Staff Name Name of Training Date Details General / Inhouse / Training provided by MANTRA
1. Dinesh M. Prajapati Fire Safety 01-07-2008 For NABL General
First Aid 24-07-2008 For NABL General
ISO/IEC 17025:2017 08-08-2008 For NABL General
Uncertainty in Measurement 10-09-2010 For NABL General
2 Jayantibhai K. Patel Uncertainty in Measurement 05-10-2013 For NABL General
Internal Audit 31-08-2016 For NABL MANTRA
ISO/IEC 17025:2017 27-06-2019 For NABL MANTRA
Fire Safety 25-02-2022 For NABL General
First Aid 25-02-2022 For NABL General
Kaizen 30-12-2023 For NABL General
3 Kirit N. Vyas Uncertainty in Measurement 05-10-2013 For NABL General
Internal Audit 31-08-2016 For NABL MANTRA
ISO/IEC 17025:2017 27-06-2019 For NABL MANTRA
Fire Safety 25-02-2022 For NABL General
First Aid 25-02-2022 For NABL General
Kaizen 30-12-2023 For NABL General
4. Sandip M. Pathak Uncertainty in Measurement 10-09-2010 For NABL General
Internal Audit 31-08-2016 For NABL MANTRA
ISO/IEC 17025:2017 27-06-2019 For NABL MANTRA
Fire Safety 25-02-2022 For NABL General
First Aid 25-02-2022 For NABL General
Kaizen 30-12-2023 For NABL General
5. Dharmesh Dineshbhai Rana Kaizen 30-12-2023 For NABL General
ISO/IEC 17025:2017 27-04-2024 For NABL General
